Docking Cart Setup
11-12 LOGIQ e – Basic Service Manual
5461614-100 English Rev. 6
Preparing for Installation
Verify Customer Order
Compare items received by the customer to that which is listed
on the delivery order. Report any items that are missing, back
ordered or damaged.
Electrical Specifications
Verify that Docking Cart is set to the correct voltage.
The Voltage settings for the Docking Cart is found on a label to
the left of the Power switch and External I/O, on the rear of the
system.
EMI Protection
This Unit has been designed to minimize the effects of Electro
Magnetic Interference (EMI). Many of the covers, shields, and
screws are provided primarily to protect the system from image
artifacts caused by this interference. For this reason, it is
imperative that all covers and hardware are installed and
secured before the unit is put into operation.
CAUTION
Connecting a Docking Cart to the wrong voltage level will most
likely destroy it.
Table 11-4: Electrical requirements for Docking Cart
PARAMETER AREA LIMITS
Voltage Range 100-240V~ 350VA
Power All applications More than or equal to 750 VA
Line Frequency All applications 50/60Hz (±2Hz)
Power Transients All applications Less than 25% of nominal peak voltage for less
than 1 millisecond for any type of transient,
including line frequency, synchronous,
asynchronous, or aperiodic transients.
Decaying Oscillation All applications Less than 15% of peak voltage for less than 1
millisecond.
