Replacement Procedure
LOGIQ e – Basic Service Manual 12-3
5461614-100 English Rev. 6
Replacement Procedure
Introduction
This section describes how to remove and install, or replace,
modules and subsystems in the Docking Cart.
Contents in this Section
• ‘Introduction’ on page 12-2
• ‘Disassembly/Re-assembly’ on page 12-3
• ‘Warning and Caution’ on page 12-3
• ‘Storage Rack (Part No. 5219976-2)’ on page 12-7
• ‘Rear Panel Assy (Part No. 5422978)’ on page 12-8
• ‘Extended Life Battery (Part No. 5486499)’ on page 12-9
Disassembly/Re-assembly
Warning and Caution
WARNING
DO NOT service or disassemble parts under FRU unit level at
any circumstances.
CAUTION
DO NOT wear the ESD wrist strap when you remove a part of
power supply unit. Turn OFF power and unplug the power cord
before removing a part of power supply unit. However be sure
to turn off power and wear the strap before you remove a circuit
boards.
WARNING
Only Qualified service personnel should remove any covers or
panels. Electrical hazards exists at several points inside.
Before thoroughly familiar with all hazardous voltages and high
current levels to avoid accidental contact.
To Next Page
