Docking Cart Setup
11-46 LOGIQ e – Basic Service Manual
5461614-100 English Rev. 6
Configuration on External Display Through DVI Connection
You can use DVI cable or VGA cable to connect the external
monitor through DVI port on Docking Cart.
Install the system on Docking Cart and power on the system.
Connect with DVI cable
1. Connect the DVI cable to the DVI port on Docking Cart and
the external monitor.
Figure 11-21. Connect DVI cable
2. Press Ctrl+Alt+V on the keyboard of the system, a dialog
box appears on the screen. In the menu list of Operating
Mode, select Clone Displays. Then Select Next.
Figure 11-22. Select Clone Displays
