Introduction
1-12 LOGIQ e – Basic Service Manual
5461614-100 English Rev. 6
Input Bottom
For use with adapter GE part
number 5460229-x
Bottom
Description Bottom
Model Rear of Docking Cart
Only for use with LOGIQ e
series (Software version R8.x.x)
Rear of Docking Cart
Made in China Rear of Docking Cart
Type/Class Label Used to indicate the degree of
safety or protection.
IP Code (IPX8)
IPX8: MKF 2-MED GP26
Indicates the degree of
protection provided by the
enclosure per IEC60 529.
IPX8 can be used in an
operating room environment.
Bottom of Footswitch
Authorized European
Representative address.
Bottom panel
United States only
Prescription Requirement label.
Bottom panel
Type BF Applied Part (man in
the box) symbol is in
accordance with IEC 878-02-03.
Beside the probe
connector
Table 1-5: Product Icons (Continued)
