Docking Cart Servicing
12-20
LOGIQ e – Basic Service Manual
5461614-100 Eng
lish Rev. 6
Bottom and Wheels
T
a
ble
12-9:
Botto
m and Wheels
Item
Part
Number
Part Name
Corresponding graphic
Qty
1000
5441308
USB HUB Assy
1
1001
5443853
Black white Rear Castor
N125 from Secure
1
1002
5454032
Black white Front Castor
N125 from Secure
1
1003
5458670
DCAC adapter for printer
1
403
405
