Setup reminders
LOGIQ e – Basic Service Manual 3-3
5461614-100 English Rev. 6
Setup reminders
Contents in this Section
• ‘Average setup time’ on page 3-3
• ‘Setup warnings’ on page 3-3
Average setup time
• Unpacking the LOGIQ e: 20 minutes
• Set up LOGIQ e wo/options: 30 minutes
• DICOM Network Configuration: 30 minutes
The LOGIQ e installation and functional checkout will take
approximately one hour. LOGIQ e consoles with optional
equipment may take slightly longer.
Setup warnings
DANGER
WHEN USING ANY TEST INSTRUMENT THAT IS CAPABLE
OF OPENING THE AC GROUND LINE (I.E., METER’S
GROUND SWITCH IS OPEN), DON’T TOUCH THE
ULTRASOUND SYSTEM!
CAUTION
To prevent electrical shock, connect the unit to a properly
grounded power outlet. Do not use a three to two prong
adapter. This defeats safety grounding.
