Product icons
LOGIQ e – Basic Service Manual 1-11
5461614-100 English Rev. 6
Product icons
The following table describes the purpose and location of safety
labels and other important information provided on the
equipment.
Label Icon Description
The following table describes the purpose and location of safety
labels and other important information provided on the
equipment.
Table 1-5: Product Icons
Label/Icon Purpose/Meaning Location
Identification and Rating Plate • Manufacture’s name and
address
• Date of manufacture
• Model and serial numbers
• Electrical ratings (Volts, Amps,
phase, and frequency)
Rating plate
Date of manufacture: The date
could be a year, year and
month, or year, month and day,
as appropriate. See ISO 8601
for date formats.
Bottom
Catalog or model number Bottom
Serial number Bottom
Direct Current: For products to
be powered from a DC supply
Bottom
ＲＥＦ
ＳＮ
