4.5 Head Section Motor
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 15
4
4.5 Head Section Motor
Tools required: (2) 10 mm wrench
13 mm socket
Ratchet
T25 Torx®
1
screwdriver
Removal
1. Set the brakes.
2. Raise the sleep surface to the highest position.
3. Raise the head section to the highest position.
If the head section motor is defective, the CPR control can be used to raise the
head section.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
4. Unplug the bed from its power source. Let the bed sit for 60 seconds so the
battery will time out.
5. Remove the headboard.
6. Remove the seat and knee sections.
7. For A model beds, do as follows, otherwise go to step 8:
a. Remove the two screws (A) and washers (B) securing the power supply
cover (C) to the power supply (D) (see figure 4-6 on page 4-16).
b. Remove the cover (C).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
