4.26 Batteries (B Model and Newer Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 83
4
4.26 Batteries (B Model and Newer Beds)
Tools required: T25 Torx®
1
screwdriver
Removal
1. Set the brakes.
2. Raise the head section to the full up position.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
4. Remove the four screws (A) that attach the battery cover (B) to the power
supply (C) (see figure 4-35 on page 4-84).
5. Remove the battery cover (B).
6. Note the position of the battery cables (D).
7. Disconnect the cables (D) from the batteries (E).
8. Remove the batteries (E) from the power supply (C).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
