CareAssist™ Bed Service Manual (MAN330 REV 4) Page 4 - 1
4
Chapter 4
Removal, Replacement, and
Adjustment Procedures
Tool and Supply Requirements
To service the CareAssist® and CareAssist® ES Bed, the following tools and
supplies are required:
• Ratchet
• Extension, 6"
• 10 mm wrench (2 required)
• 13 mm wrench
• 13 mm socket
• T25 Torx®
1
screwdriver
• T15 Torx® screwdriver
• TR25 Tamper resistant Torx® screwdriver
• 10 mm hex key
• Small screwdriver
• #2 phillips head screwdriver
• Soft faced hammer
• 8 mm pin punch
• Loctite®
2
242 adhesive
• E-ring installation tool
• (2) Jack stand
• Scissor jack
• 3/32" punch
• Marking pen
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
2. Loctite® is a registered trademark of Loctite Corporation, Inc.
