4.8 Foot Section Motor
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 27
4
4.8 Foot Section Motor
Tools required: 13 mm socket
Ratchet
Extension
E-ring installation tool
T25 Torx®
1
screwdriver
Removal
1. Set the brakes.
2. Raise the sleep surface to the highest position.
3. Raise the head section to the highest position.
4. Remove the seat and knee sections.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
5. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
6. For A model beds, do as follows, otherwise go to step 7.
a. Remove the two screws (A) and washers (B) securing the power supply
cover (C) to the power supply (D) (see figure 4-14 on page 4-28).
b. Remove the power supply cover (C).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
