4.22 Foot Hilow Column (B Model and Newer Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 68 CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4)
4.22 Foot Hilow Column (B Model and Newer Beds)
Tools required: 13 mm socket Ratchet
Extension (2) Jack stands
T25 Torx®
1
screwdriver T15 Torx® screwdriver
Wire cutters Antistatic strap
Vise-Grips®
2
Marking pen
String, 10' (305 cm)
Removal
1. Set the brakes.
2. Remove the footboard.
3. Raise the head section to the full up position.
4. Remove the seat section of the sleep deck.
5. Remove the thigh section of the sleep deck.
Do not work under an unsupported load. Install appropriate supports.
Failure to do so could cause personal injury or equipment damage.
6. Place the jack stands under the articulating frame.
7. Lower the articulating frame onto the jack stands.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
8. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
9. Remove the two screws (A) from the retainers (C) (see figure 4-30 on page
4-69).
10. Remove the retainers (C).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
2. Vise-Grip® is a registered trademark of American Tool Companies, Inc.
