4.3 Power Supply (A Model Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 9
4
4.3 Power Supply (A Model Beds)
Tools required: 13 mm socket
Ratchet
Extension, 6"
Removal
1. Set the brakes.
2. Raise the head section to the high position.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
4. Remove the two screws (A) and washers (B) securing the cover (C) to the
power supply (D) (see figure 4-3 on page 4-9).
Figure 4-3. Power Supply
To Next Page
