7.6 Traction Frame Support Module—P1181B
Chapter 7: Accessories
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 7 - 7
7
7.6 Traction Frame Support Module—P1181B
Tools required: 19mm wrench
Ratchet
Torque wrench,5 to 75 ft-lb (7 to 102 N·m)
Installation
1. Set the brakes.
2. Raise the bed to the full up position.
Failure to unplug the bed could cause personal injury or equipment
damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds to let
the battery time out.
4. Do as follows for each side:
a. Install one bolt (A) and washer (F) in the inner hole (B) of the module
(C) ((see figure 7-2 on page 7-8)).
b. Install, but do not tighten, one nut plate (D) on the bolt (A).
5. Move the module (C) under the bed (E).
6. Lift the module (C) so it touches the bottom of the bed (E).
7. Turn the nut plate (D) so that it supports the weight of the module (C).
8. Install two bolts (A) and washer (F) through the outer holes in the module
(C) and into the nut plate (D).
9. Slide the module (C) so it is against the hilow tower.
10. Tighten all four bolts (A) to 40 ft-lb (54 N·m) of torque.
