Chapter 1: Introduction
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 1 - 5
1
Electrical Specification
Table 1-5. AC Power Requirements
Table 1-6. Auxiliary Outlet Power Specifications (120 V Beds Only) (Beds
with the Optional Auxiliary Outlet)
Table 1-7. Fuse Specifications
Nominal Power Distribution
Voltage (Volts)
Nominal Power Distribution
Frequency (Hertz)
Maximum Equipment
Current (Amps)
120 60
6.0
a
a. North American power supply configuration.
100-120 50/60 7.5
127 50/60 6.0
220/230/240 50/60 3.5
Condition Range
Auxiliary Outlet 120 V AC, 60 Hz, 8 A outlet, electrically iso-
lated from the bed’s mains power. Equipped
with an 8 A, single-pole, resetable circuit
breaker.
Condition Range
Battery fuse 10 A, 32 V~, ATO
Mains fuse 2 each 2.5 A, 250 V~, 5 x 20 mm, UL
198G Slo-Blo®
a
or equivalent (220, 230,
and 240 V beds)
2 each 5 A, 250 V~,.25" x 1.25", UL 198G
Slo-Blo® or equivalent (100 V through
127 V beds)
a. Slo-Blo® is a registered trademark of Littlefuse, Inc.

Hill-Rom CareAssist P1170 Specifications

General

Brand	Hill-Rom
Model	CareAssist P1170
Category	Medical Equipment
Language	English
