4.15 Interface P.C. Board (A Model Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 49
4
4.15 Interface P.C. Board (A Model Beds)
Tools required: T15 Torx®
1
screwdriver
T25 Torx® screwdriver
Removal
1. Set the brakes.
2. Raise the bed to its highest position.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
The interface P.C. board is mounted on the interface box cover.
4. Remove the nine screws (A) securing the interface box cover (B) to the
interface box (C) (see figure 4-23 on page 4-50).
5. Lower the box cover (B).
6. Disconnect all cables from the interface P.C. board (D).
7. Remove the six screws (E) securing the interface P.C. board (D) to the box
cover (B).
8. Remove the interface P.C. board (D).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
