4.36 Head-End Brake/Steer Pedal
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 108 CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4)
4.36 Head-End Brake/Steer Pedal
Tools required: 13 mm wrench
Removal
1. Set the foot end brakes.
2. Raise the bed to its highest position.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
4. Remove the screws (A) and washers (B) from the brake pedal (C). (see
figure 4-47 on page 4-109).
5. Remove the brake pedal (C) and spacers (D) from the brake rod (E).
