7.4 Mattress Pad Extender—P734EA1
Chapter 7: Accessories
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 7 - 5
7
7.4 Mattress Pad Extender—P734EA1
Tools required: None
Installation
1. Extend the foot section (A) (see figure 7-1 on page 7-5).
Figure 7-1. Mattress Pad Extender
2. Insert the extender between the footboard and mattress.
Removal
Reverse the installation procedure to remove mattress pad extender.
m330_121
A
