4.24 Scale Control Pod (B Model and Newer Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 77
4
4.24 Scale Control Pod (B Model and Newer Beds)
Tools required: (2) small-bladed screwdriver
Antistatic strap
T15 Torx®
1
screwdriver
Removal
1. Set the brakes.
2. Raise the siderail to the up and locked position.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
4. Remove the spacer (A) (see figure 4-33 on page 4-78).
5. Slide the pod (B) towards the head end of the siderail (C).
6. Pull out the foot end of the pod (B).
7. Slide the pod (B) toward the foot end of the siderail (C) and remove it from
the siderail (C).
8. Remove the four screws (D) from the back of the pod (B).
9. Remove the back of the pod (E).
10. Note the routing of the cable (F).
11. Disconnect the cable (F) from the P.C. board (G).
12. Remove the weldment (H) from the spring (I).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
