4.2 AC Power Cord (A Model Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 6 CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4)
4.2 AC Power Cord (A Model Beds)
Tools required: 13 mm ratchet wrench
T25 Torx®
1
tamper resistant screwdriver
Removal
1. Set the brakes.
2. Raise the head section to its highest position.
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
3. Unplug the bed from its power source. Let the bed sit for 60 seconds so the
battery will time out.
4. Remove the headboard.
5. Remove the two screws (A) and washers (B) from the power supply cover
(C) (see figure 4-2 on page 4-7).
6. Remove the cover (C).
7. Disconnect the power cord connector (D) from the fuse board (E).
8. Remove the screw (F) securing the power cord ground wire (G) to the bed
frame (H).
9. Remove the two screws (I) securing the power cord strain relief (J) to the
bed frame (H).
10. Remove the power cord (K).
Replacement
1. Perform the removal procedure in reverse order.
2. Plug the bed into an appropriate power source.
3. Raise and lower the bed fully to make sure the power cord expands and
contracts without any problems.
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
