IDS X-Series Training v2.7
Option 97 – Manual Auto Test
If you want to test that signals are being transmitted via telephone, this option will force the X-Series alarm
to transmit an auto test.
Master Mode menu
The master mode menu adds more functionality to the X-Series, as shown in the table below.
Note: As before the first key press must be held until a beep is heard. (Approx. 3 seconds)
Changing Partitions
This option allows a user to access different partitions on a keypad.
[Mode] [1] [*] [Partition] [*]
Note: This will only be available if the keypad is a global keypad. (Keypad Options Location 251 to
258)
Changing Stay Profiles
There are four stay profiles that can be created for different requirements, for example: When staying at
home in the evening the outside detectors can be activated while the indoor detectors are bypassed.
Then when going to bed all external and internal detectors except the bedrooms are made active by
changing the profile.
[Mode] [2] [*] [Stay Profile] [*]
Manually Setting Outputs
The X-Series Outputs, can be manually triggered on or off, via the keypad.
[Mode] [3] [*] [Output [*]
Instruction
Key presses
Press and hold the [*] key for 3 seconds
[*]
Enter the master code, followed by the [*] key
[1][2][3][4] [*]
Enter the value to default the remote receiver, followed by the [*] key
[9][7] [*]
When complete press the [#] key
[#]
Option
Description
1
Change between partitions
2
Change between stay profiles
3
Toggle onboard outputs
4
Toggle between LCD alphanumeric display and LED simulation display
Press and hold
until beep
Menu
Option
Partition
Number
Press and
hold until
beep
Stay Profile
Menu Option
Stay Profile
Number
Press and hold
until beep
Output
triggering Menu
Option
Output Number
