IDS X Series Training Manual

58
IDS X-Series Training v2.7
Location 303 Global Reporting
Location Type: Extended
Sub Loc.
Description
Explanation
1
Wireless Detector
Supervision Failure
Each device checks in with the controller at a predetermined time and if this signal
is not received, the alarm company is alerted that it has gone missing.
2
Wireless Detector
Supervision Restore
If the wireless device starts communicating after being missing a restoral is sent.
3
Wireless Receiver
Signal Jam
If the receiver detects a signal that could block effective communication from the
devices that it is monitoring an alert is sent to the monitoring company.
4
Wireless Receiver
Signal Restore
When the signal causing the jam has been removed a restoral is sent.
5
Wireless Detector
RSSI Low
Each detectors signal strength is checked and if the signal strength drops below
20% a low RSSI is sent.
6
Wireless Detector
RSSI Restore
Once the signal strength of a device increases above 20% an RSSI restore is sent.
7
Dedicated Panic
On board is a dedicated panic zone, when triggered this code is sent.
8
Test Report
The X-Series alarm panel can be programmed to send test signals to confirm that
it is still alive.
9
Download Report
Code
After the system has been connected to by IDSwift software a code is sent.
10
AC Fail on Smart
Power Supply
This code is sent when the main electrical supply to the Smart PSU has failed and
the system is running on the backup battery.
11
AC Restore on Smart
PSU
This code is sent when the main electrical supply is restored to the Smart PSU.
12
Low Battery on Smart
PSU
When the Smart PSU detects that the battery voltage has reached 10.5V this code
is sent to warn the company that it is about to switch off.
13
Battery Restore on
Smart PSU
Once the battery is charged this code will be sent to confirm the battery is
charged.
14
Fuse Fail on
SmartPSU
If the fuse protecting the Smart PSU auxiliary 12V output goes faulty this code is
sent to alert the security company.
15
Fuse Restore on
Smart PSU
When the fuse fault is corrected a restore is sent.
Location 304 to 335: Zone Reporting
Location Type: Extended
Each location represents a set of 16 zones, for example;
 Location 304 is zones 1-16
 Location 305 is zones 17-32
 Location 306 is zones 33-48
 Location 307 is zones 39-64
Location
Sub Loc.
Description
Explanation
304 to 307
1 to 16
Zone Alarm Reporting
When the system is armed, a 24Hr zone or a panic zone is triggered
this code is reported.
308 to 311
1 to 16
Zone Alarm Restoral
When the zone restores after being violated this code is sent.
312 to 315
1 to 16
Zone Tamper
Reporting
If the tamper monitoring option is enabled and a tamper signal is
received this code is sent.
316 to 319
1 to 16
Zone Tamper Restoral
Once the tamper condition is corrected a restoral is sent.
320 to 323
1 to 16
Zone Bypass
Reporting
If a zone is bypassed and the alarm is armed this code is sent to
report which zones are inactive.
324 to 327
1 to 16
Forced Arming
If the system is programmed to bypass zones that are violated when
arming, this code is sent to alert the monitoring company.
328 to 331
1 to 16
Swinger Shutdown
Reporting
If swinger shutdown has been enabled and the alarm automatically
shuts down a zone that has violated the swinger shutdown settings.
332 to 335
1 to 16
Swinger Shutdown
Restore
The system can be set to try restore a zone that has been disabled
by swing shutdown and if it’s able to then this code is sent.
