IDS X Series Training Manual

38
IDS X-Series Training v2.7
Location 48: Download Options
Location Type: Bitmap
The IDS X-Series alarm system can be up/downloaded with IDSwift software over a standard phone line, via
an IDS modem. The following options help the system to deal with incoming calls.
Location 49: Number of Rings to Answer
Location Type: Standard
When the panel detects this number of rings on a phone line it will automatically pick up the phone if
automatic pickup is enabled in location 48.
Valid Range: 1 - 15
Default: 15
Location 51 to 54: Entering a Telephone Number
Location Type: Standard
When entering phone numbers please follow these instructions:
To dial a “*” enter [MODE] [1]
To dial a “#” enter [MODE] [2]
For a “12-second pause” enter [MODE] [3] (On the LCD keypad it will be displayed as a “+”)
For a “8-second pause” enter [MODE] [4] (On the LCD keypad it will be displayed as a “=”)
For a “4-second pause” enter [MODE] [5] (On the LCD keypad it will be displayed as a “-“)
Note: [MODE] [0] will clear the phone number.
Exercise:
The control rooms’ phone number is 0860105937. The alarm is installed in a building with a
switchboard and 0 has to be dialled to get a line and then must wait 4 seconds before dialling.
Instructions
Key presses
Enter location 51
[5][1] [*]
Enter the value needed to dial
[0] [mode] [5] [0] [8] [6] [0] [1] [0] [5] [9] [3] [7] [*]
Location 55: Serial Reporting Telephone Number
Location Type: Standard
The telephone number that the serially connected device must dial to report any signals.
Note: This option is only entered if the serial device has this option built in.
LED
Default
Action
Description
1
ON
Fax Defeat
The system monitors the line and if the phone rings twice and stops, then
10 seconds later rings again, the panel will answer before any other device
that may be on the line.
2
ON
Forced Answer
Pressing and holding down the [8] key for 3 seconds will force the alarm
system to pick up the telephone line.
3
ON
Auto Pickup
By default if the telephone line rings 15 times the alarm will pick up the line.
Location 49.
