Extending Contact ID Zone Reporting
Location Type: Extended
Locations 304 to 335 can be programmed with a value that will change the contact ID reporting code for
each zone to extend what can be connected to each zone and what is reported to the control room.
Example: If a gas detector is connect to zone 8
By entering 26 into location 304 sub-location 8, whenever zone 8 triggers, a contact ID code of 151 (Gas
detected) is sent to the control room.
Please see Appendix at the end of the manual for all values.
Value
CID
Description
Value
CID
Description
01
100
Medical Zone
3C
303
RAM Checksum bad Zone
02
101
Personal Emergency Zone
3D
304
ROM checksum bad Zone
26
151
Gas detected Zone
3E
305
System reset Zone
28
153
Loss of heat Zone
3F
306
Panel programming changed Zone
Location 336 to 340: Partition Reporting Codes
Location Type: Extended
There is a sub-location for each of the 8 partitions.
[INSTALLER CODE] [*] [LOCATION] [*] [SUB LOC] [*] [REPORTING CODE] [*]
Loc
Sub Loc
Description
Explanation
336
1 to 8
Duress
Reporting
A user code can be programmed to send a duress signal to alert the security
company of a life threatening situation.
337
1 to 8
Keypad Panic
This code is sent when the panic button on the keypad is pressed.
338
1 to 8
Fire Alarm
If a fire is detected or the fire key is pressed this code will be reported.
339
1 to 8
Medical Key
A medical code is sent alerting the monitoring company to send an ambulance.
340
1 to 8
Keypad Lockout
This code is sent if the keypad locks itself due to incorrect codes being used.
Location 342 to 373: User Reporting Codes
Location Type: Extended
Each location represents a set of 16 users:
 Location 342 are users 1-16
 Location 343 are users 17-32
 Location 344 are users 33-48
 Location 345 are users 39-64
 Location 346 are users 65-80
 Location 347 are users 81-96
 Location 348 are users 97-112
 Location 349 are users 113-128
[INSTALLER CODE] [*] [LOCATION] [*] [SUB LOC] [*] [REPORTING CODE] [*]
Loc
Sub Loc
Description
Explanation
342 to 349
1 to 16
Close Reporting
Every time a user arms the alarm this code is sent.
350 to 357
1 to 16
Stay Close Reporting
If the user arms in stay mode this code is sent.
358 to 365
1 to 16
Open Reporting
Every time a user disarms the alarm this code is sent.
366 to 373
1 to 16
Siren Cancel
Reporting
When a user cancels the siren this code is sent.
Location 374: Quick Close Reporting Codes per Partition
Location Type: Extended
There is a sub-location for each of the 8 partitions.
These reporting codes are sent when someone away arms the system using the quick arm key, [1]
Location 375: Quick Stay Reporting Codes per Partition
Location Type: Extended
There is a sub-location for each of the 8 partitions.
These reporting codes are sent when someone stay arms the system using the quick Stay arm key, [5].
