IDS X Series Training Manual

72
IDS X-Series Training v2.7
Location 600 - 616 Voice Module Reporting Telephone numbers
Location Type: Standard
The voice module, if installed, will report programmed events to the telephone numbers entered into these
locations. Depending on the location the telephone number is entered into will depend on the partition the
person can interact with via the voice module.
The table below shows which locations belong to which partitions.
Location
Partitions
User Slot
Location
Partitions
User Slot
600
All
609 & 610
5
50 to 59
601 & 602
1
10 to 19
611 & 612
6
60 to 69
603 & 604
2
20 to 29
613 & 614
7
70 to 79
605 & 606
3
30 to 39
615 & 616
8
80 to 89
607 & 608
4
40 to 49
Note: The user code must have permissions to the partition the voice module is dialling. For versions below
2.41 the user code must also be in the correct user slot numbers for the partition, as seen above.
V2.41 and higher the user can be in any slot number as long as Voice Login is enabled for that user.
Location 617: User Reporting Codes
Location Type: Bitmap
For open and close reporting all user options are enabled by default therefore to enable reporting the
partition options, Locations 211 to 218 must be enabled. In this location you can enable or disable per
user. Sub-locations 6 – 10 are used for Voice Module reporting only.
Option
Default
Action
Description
1
ON
Close Reporting
Enable if a close signal is to be sent to the security company.
2
ON
Stay Close Reporting
Enable if a stay close signal is to be sent.
3
ON
Open Reporting
Enable if an open signal is to be sent.
4
OFF
Siren Cancel Reporting
Enable if the siren is active and a user cancels the siren.
5
Reserved
6
OFF
AC Fail Reporting
A signal is sent when the electricity goes off.
7
OFF
AC Restore Reporting
A signal is sent when the electricity is stored.
8
OFF
Low Battery Reporting
A signal is sent when the battery reaches 10.5V.
9
ON
Auto Test Reporting
This is a signal reporting that the alarm is communicating.
10
OFF
Zone Bypassing Reporting
A signal is sent when zones are bypassed.
Location 618: User Split Reporting
Location Type: Bitmap
Select which group of phone numbers to report the user reporting codes per code.
Option
Default
Action
Description
1
OFF
Telephone Module 1
Close reporting Telephone module 1 or 2.
2
OFF
Telephone Module 1
Stay Close reporting Telephone module 1 or 2.
3
OFF
Telephone Module 1
Open signal reporting Telephone module 1 or 2.
4
OFF
Telephone Module 1
Siren cancelled reporting Telephone module 1 or 2.
5
Reserved
6
OFF
Telephone Module 1
AC Fail Reporting telephone module 1 or 2.
7
OFF
Telephone Module 1
AC restored report Telephone module 1 or 2.
8
OFF
Telephone Module 1
Low Battery reporting Telephone module 1 or 2.
9
OFF
Telephone Module 1
Auto test report telephone module 1 or 2.
10
OFF
Telephone Module 1
Zones bypassed reporting Telephone module 1 or 2.
