IDS X-Series Training v2.7 | Triggering Outputs
67
Location 447: Keypad Output On Time
Location Type: Extended
This location has 8 sub-locations representing the output on each keypad.
[Installer Code] [*] [4] [5] [7] [*] [Output No.] [*] [h] [h] [m] [m] [*]
Data format: HHmm
Valid Range: 0000 2359 (2400 disables)
Default: 2400
Scheduled Output Off Times
The next few locations are used to schedule the output turn off time.
Location 448: Onboard Output Off Time
Location Type: Extended
This location has 5 sub-locations representing outputs 1 to 5 on the main system board.
[Installer Code] [*] [4] [4] [8] [*] [Output No.] [*] [h] [h] [m] [m] [*]
Data format: HHmm
Valid Range: 0000 2359 (2400 disables)
Default: 2400
Location 449 to 454: Zone Expander Output Off Time
Location Type: Extended
This location has 2 sub-locations representing the 2 outputs on each expander.
[Installer Code] [*] [Location] [Output No.] [*] [h] [h] [m] [m] [*]
Data format: HHmm
Valid Range: 0000 2359 (2400 disables)
Default: 2400
Location 455 to 456: Zone Expander Output Off Time
Location Type: Extended
Each location has 8 sub-locations representing the 8 outputs on each expander.
[Installer Code] [*] [Location] [*] [Output No.] [*] [h] [h] [m] [m] [*]
Data format: HHmm
Valid Range: 0000 2359 (2400 disables)
Default: 2400
Location 457: Keypad Output Off Time
Location Type: Extended
This location has 8 sub-locations representing the output on each keypad.
[Installer Code] [*] [4] [5] [7] [*] [Output No.] [*] [h] [h] [m] [m] [*]
Data format: HHmm
Valid Range: 0000 2359 (2400 disables)
Default: 2400
