IDS X Series Training Manual

IDS X-Series Training v2.7 | Quick Guide
107
Quick Guide
Description
Programming
Add a User Code
[*] [Master Code] [*] [0] [*] [New Code] [*]
Edit a User Code
[*] [Master Code] [*] [1] [*] [Old Code] [*] [New Code] [*]
Delete a User Code
by Code
[*] [Master Code] [*] [2] [*] [User Code] [*]
Add/Edit Slot
[*] [Master Code] [*] [3] [*] [Slot Number] [*] [User Code] [*]
Delete a User Code
by Slot Number
[*] [Master Code] [*] [4] [*] [Slot Number] [*]
View a Slot Number
[*] [Master Code] [*] [5] [*] [User Code] [*]
View the Slot number via the zone LEDs
Edit User Code
Properties
[*] [Master Code] [*] [1] [0] [*] [User Code] [*] [Bitmap] [*] 1 = Master 2 = Duress 3 =
Arm to Disarm Code 4 = Arm 5 = Disarm 6 = Global Arm/Disarm Code
7 = Output trigger code
Allocate a User Code
to a Partition
[*] [Master Code] [*] [1] [1] [*] [User Code] [*] [Partition] [*]
User Outputs
[*] [Master Code] [*] [1] [3] [*] [User Code] [*] [Output No.] [*] [Output Action] [*]
User RC Enable*
[*] [Master Code] [*] [1] [4] [*] [User Code] [*] [Bitmap] [*] (Firmware ver. 1.08 & below)
User RC Module*
[*] [Master Code] [*] [1] [5] [*] [User Code] [*] [Bitmap] [*] (Firmware ver. 1.08 & below)
Add Remotes –
Basic
[*] [Master Code] [*] [2] [0] [*] [Receiver No] [*] [User Code] [*] [*] [Press RT Button]
Add Remotes –
Advanced
[*] [Master Code] [*] [2] [1] [*] [Receiver No] [*] [User Code] [*] [Management No] [*] [*]
[Press RT Button]
Delete Remote
[*] [Master Code] [*] [2] [2] [*] [Receiver No] [*] [User Code] [*]
Button Properties
[*] [Master Code] [*] [2] [3] [*] [Receiver No] [*] [Button No] [*] [Properties] [*]
Relay Properties
[*] [Master Code] [*] [2] [4] [*] [Receiver No] [*] [Relay No] [*] [Properties] [*]
Relay Pulse Time
[*] [Master Code] [*] [2] [5] [*] [Receiver No] [*] [Time] [*]
Defaulting Receiver
[*] [Master Code] [*] [2] [6] [*] [Receiver No] [*] [*]
Identifying Receiver
[*] [Master Code] [*] [2] [7] [*] [Receiver No] [*]
Testing Receiver
[*] [Master Code] [*] [2] [8] [*] [Receiver No] [*] [Press RT Button]
Receiver Capacity
[*] [Master Code] [*] [2] [9] [*] [Receiver No] [*]
Edit Zone Name via
LCD Keypad
[*] [Master Code] [*] [3] [0] [*] [Zone No] [*] [*] [Name] [*]
Edit the Time
[*] [Master Code] [*] [4] [0] [*] [Time] [*]
Edit the Date
[*] [Master Code] [*] [4] [1] [*] [Date] [*]
Trigger an Auto Test
[*] [Master Code] [*] [9] [7] [*]
Change Partitions
[Mode] [1] [*] [Partition Number] [*]
Toggle Outputs
[Mode] [3] [*] [1, 2, 3, 4 or 5] [*]
1 – 5 is onboard outputs 1 – 5
Bypassing/Un-
bypassing a Zone
[9] [Master Code] [*] [Zone Number] [*]
Alarm Memory
[0] Displays zones violated.
View Trouble
Conditions
[7]
1 = AC Mains Fail
9 = Tamper on Peripheral Device
2 = No Communication
10 = Comms Loss to Peripheral Device
3 = Phone Line
11 = Loss/low Power to Peripheral Device
4 = Siren Tamper
12 = Wireless Battery low
5 = Low Battery
13 = Wireless Supervision Failure
6 = 12V Aux Fuse
14 = Wireless RF Jam
7 = Engineer Reset
15 = Wireless low RSSI
8 = Box Tamper
16 = Zone Tamper
