IDS X-Series Training v2.7
Location 573 Global Split Reporting
Location Type: Bitmap
Location 574 Global Split Reporting
Location Type: Bitmap
LED
Default
Action
Explanation
Split
Reporting
Option
Default
1
OFF
Comms Restored
When the system is able to communicate
after a failure a restoral is sent.
9
OFF
2
OFF
Comms Tamper
Restore
If the lines went down and when they start
working again a restore is sent.
10
OFF
3
OFF
Siren Restore
If the siren went missing and is reconnected
a restore will be sent.
11
OFF
4
OFF
Battery Restore
After a battery low is reported and the
battery is changed or charged a restore will
be sent.
12
OFF
5
OFF
Aux 12V Restored
After a short circuit or too much current
being drawn is fixed the fuse will restore
and send a signal.
13
OFF
6
OFF
Installer Reset Restored
After an installer reset required condition is
reset a signal will be sent.
14
OFF
7
ON
Box Tamper Restored
When the box that the system is housed is
closed a restore is sent.
15
OFF
8
ON
Bus Device Tamper
Restored
When the device on the keypad bus that
was tampered is restored a signal will be
sent.
16
OFF
LED
Default
Action
Explanation
Split
Reporting
Option
Default
1
OFF
Bus Device Comms
Restored
When a device has stopped
communicating on the bus and when
communication is restored a signal is sent
to confirm this.
9
OFF
2
OFF
Bus Device Battery
Restored
A device that reported a low will send a
restore when the battery voltage is
restored.
10
OFF
3
OFF
Wireless Detector
Battery Restored
Once the wireless devices battery is
changed it will respond by sending a
restore.
11
OFF
4
OFF
Wireless Detector
Supervision Restored
When a device starts communicating after
being marked as missing by the system a
supervision restoral is sent.
12
OFF
5
OFF
Wireless Receiver Jam
Restored
After detecting a signal that could cause
wireless devices from communicating is
switched off a restoral will be sent.
13
OFF
6
OFF
Wireless Detector RSSI
Low Restored
A device that recorded a low signal
recovers and the signal comes up to an
acceptable level a restoral will be sent.
14
OFF
7
ON
Dedicated Panic
The X-Series alarm panel has a dedicated
panic onboard and if this is triggered a
panic signal will be sent.
15
OFF
8
ON
Test Report
The alarm can be configured to send a test
report every 1 hours to every 14 days.
16
OFF
