IDS X-Series Training v2.7
Partition Dependant Events:
Location Type: Extended
There is a sub-location for each of the 8 partitions.
Loc
Event
Description
Default
390
Close Programmable
Output
Enter the output and action to be performed when the alarm is away
armed.
0300
391
Stay Close Programmable
Output
When the alarm is armed in the stay mode, someone is staying on the
premises and internal zones are automatically bypassed.
0000
392
Open Programmable
Output
Open means disarmed from either away or stay armed.
0301
393
Cancel Programmable
Output
By disarming the partition an output can be turned off.
0000
394
Alarm Restoral
Programmable Output
This is when a device has triggered and comes back to the normal
working state.
0000
395
Bypass Programmable
Output
When a zone is disabled using the bypass key [9].
0000
396
Forced Arm Programmable
Output
If forced arm has been enabled and zones have been automatically
bypassed by the system to allow the panel to arm.
0000
397
Zone Tamper
Programmable Output
If tamper has been enabled on a zone and the tamper switch on the
device is triggered.
0000
398
Zone Tamper Restoral
Programmable Output
When the tamper switch goes back to normal.
0000
399
Zone Shutdown
Programmable Output
If enabled and a zone does get bypassed.
0000
400
Zone Shutdown Restoral
Programmable Output
When the zone is un-bypassed at the auto test time if enabled to do so.
0000
401
Keypad Panic
Programmable Output
When the panic on the keypad is pressed.
0102
402
Keypad Fire
Programmable Output
When the fire button on the keypad is pressed.
0402
403
Keypad Medical
Programmable Output
When the medical button on the keypad is pressed.
0502
404
Keypad Lockout
Programmable Output
If someone randomly presses keys and all parameters are met in
locations 20 and the keypad options menu (251 to 258) the keypad will
lock for the time specified in location 21.
0000
405
Duress Programmable
Output
A duress code can be programmed into the system to mimic a user
code but will send a duress (panic) signal to the control room.
0102
406
Verifies Cross-Zone Trigger
Programmable Output
This output when programmed will trigger when an alarm is caused by
zones that are cross zoned. I.e. The number of triggers in the time
allocated is exceeded.
0000
407
Burglary Programmable
Output
Triggered when the alarm is armed and a zone is triggered.
0202
408
Panic Programmable
Output
If any panic event is triggered.
0102
409
Fire Programmable Output
If a fire zone is triggered.
0402
410
Tamper Zone
Programmable Output
If a zone is set to be of the zone type tamper.
0000
