Inovance SV820N Series User Manual

- 10 -
1 Servo System Selection
1
1.1.2 Unit Model (Maintenance Options)
Figure 1-5 Unit model description
SV82 – M – 2A
Mark Serial Number
SV82 Servo drive
Mark Option Mark
M Unit module
Mark
Unit Model
1A 1.1 A
1B
1.6 A
1C
2.8 A
1D 4.6 A
2A 1.1 A
2B 1.6 A
2C 2.8 A
2D 4.6 A
Single axis drive unit (rated current)
Double axis drive unit
(rated current per axis)
Power supply unit
N1S
Control board type:
network-type
Rated power: 1 kW
N2S
Control board type:
network-type
Rated power: 2 kW
Note
Units are for the replacement of damaged ones in the original servo drive only. Contact your
supplier if any unit needs replacing.
1.2 TechnicalSpecications
1.2.1 BasicSpecications
Item Description
Basic
specications
Control mode
220Vsingle/three-phasefull-bridgerectication
IGBT PWM control, sine wave current drive mode
Feedback Serialandincremental:23bitsor20bits
Use conditions
Use/Storage
temperature
0–45
℃
(derating is required in case of an ambient
temperature higher than 45
℃
)/–40–+70
℃
Use/Storage humidity Below 90% RH (no condensation)
Vibration/Impact
resistance
4.9 m/s
2
/19.6 m/s
2
IP rating IP20 (except for cable entry)
Pollution level Level 2
Altitude Below 1,000 m
