Inovance SV820N Series User Manual

- 43 -
3 Wiring
3
Note
Framesizeofthemotorindicatesthewidthofthemotorange.
The power cable colors are subject to the actual cables. The cable colors mentioned in the guide are colors
of all Inovance cables.
3.3.2 WiringoftheMotorPowerCableswithouttheBrake
Whenmotorswithoutabrakeareconnectedtothedrive,itisnotnecessarytoconnectthetwobrakesignal
terminals(BR+andBR–),asshowninthegurebelow.
Otherconnectionsshouldbeperformedinthesamewayasthemotorswithbrake.Referto"3.3.1Connec-
tionofpowercablesofmotorwithabrake"fordetails.
Figure 3-8 Connectiondiagramofpowercablesofamotorwithoutabrake
BR+
BR-
PE
U
V
W
Yellow/
Green-PE
V
White-U
Black
-V
Red-W
U
W
PE
