Inovance SV820N Series User Manual

- 26 -
2 Installation
2
2.1.3 Installation Method
Thisproductsupportsbackplatemountingviathreeinstallationholesonthebodyandcanbexedtothe
installation surface with M4 screws.
Installation method:
Markthepositionoftappedholesforinstallationonthebaseplate.Drillholesforxingthescrewsonthe
base plate.
This product must be installed on the base plate vertically.
Belowistheinstallationdiagram:
Figure 2-5 Backplatemountingdiagram
Recommendedtorqueforinstallation(N.M):
WhentheM4screwsareusedtoxtheproduct,thetorqueisrecommendedtobe1.2N.M.
Item M3 M4 M5 M6 M8 M10 M12
Electric connection 0.55 1.2 2.8 6 13 25 50
