Inovance SV820N Series User Manual

- 47 -
3 Wiring
3
3.4.2 Connection of Absolute Encoder Cable
Figure 3-10 Example of connection of signal cable and battery box of absolute encoder
Battery box
Battery box
Encoder signal
cable
Color of battery box outer lead:
Figure 3-11 Battery box outer lead of absolute encoder
Red: Positive
Black:
Negative
Note
Storethebatteryintherequiredambienttemperatureandensurereliablecontactandsufcient
electricity. Failure to comply may cause loss of the encoder position information.
