Inovance SV820N Series User Manual

- 41 -
3 Wiring
3
3.1.6 SpecicationsofMainCircuitPeripheralParts
Recommendedcircuitbreakerandelectromagneticcontactor:
Table 3-5 Modelsofrecommendedcircuitbreakerandelectromagneticcontactor
Main Circuit Power Supply Drive Model
RecommendedCircuitBreaker Recommended Contactor
Current (A) Schneider Model Current (A) Schneider Model
Single/Three-phase 220 V
SV820N1S****
SV820N2S****
6 OSMC32N3C6 9 LC1 D09
3.2 Wiring of Motor Cables Between Servo Drive and Servo Motor
A complete servo drive consists of two drive units with each drive unit supporting two motors. When connect-
ingmotorstothedriveunits,identifytheterminalsilkprintonthedriveunitsandusecorrectterminalsfor
wiring (X1 matches with X3, and X2 matches with X4)
X1
X2
X4
X3
Actualconnectiondiagram:
