Inovance SV820N Series User Manual

- 70 -
4 Operation Panel
4
Display Name Situation Meaning
1–8
Communication
state
It displays the state of EtherCAT
state machine in the slave
station in character form.
1:Initializationstate
2:Pre-operationstate
4:Safeoperationstate
8:Operationstate
-
CN4 connection
indication
CN4 is connected
successfully when
EtherCAT is output
Segmentoff:Nocommunication
layer is detected in the physical
layer.
Segmenton:Communication
connection is set up in the
physical layer.
-
CN5 connection
indication
CN5 is connected
successfully when
EtherCAT is output
4.2.2 Parameter Display
The SV820N series has 14 groups of function codes based on parameter functions. The function codes can
belocatedquicklybasedonthegroupitbelongsto.Refertotheappendixtoviewthefunctioncodetable.
Inthissection,thecurrentoperationaxis3istakenasanexample.
Parameter group display
Display Name Content
HXX.YY Function code group
XX:Functioncodegroupnumber
YY:Offsetinfunctioncodegroup
Forexample,functioncodeH02-00isdisplayedasfollows:
Display Name Content
Function code H02-00
02:Functioncodegroupnumber
00:Offsetinfunctioncodegroup
Display of data of different lengths and negative number
■ With-symbol number of 4 digits and below and without-symbol number of 5 digits and below
Such a number is display with 5-digit 7-segment LED display. The highest digit "-" indicates the negative
symbol.
Forexample,–9999isdisplayedasfollows:
Forexample,65535isdisplayedasfollows:
