INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
143
Function
code
Name
Detailed instruction of parameters
Default
value
0–2
Tens: Inductance compensation selection
0: Compensate
1: Not compensate
Hundreds: High speed control mode
0: Mode 0
1: Mode 1
P03.29
Torque control mode
0x0000–0x7111
Ones: Torque command selection
0: Torque reference
1: Torque current reference
Tens: Torque compensation direction at 0
speed
0: Positive
1: Negative
Hundreds: ASR integral separation setting
0: Disabled
1: Enabled
Thousands: Torque control word setting
Bit0: Torque command filtering mode
0: Inertia filter
1: Linear ACC/DEC filtering
Bit1–2: ACC/DEC time for rotating speed
upper limit
0: No ACC/DEC time
1: ACC/DEC time 1
2: ACC/DEC time 2
3: ACC/DEC time 3
0x0001
P03.30
Low-speed friction torque
0–50.0% (rated torque of the motor)
0.0%
P03.31
High-speed friction torque
0–50.0% (rated torque of the motor)
0.0%
P03.32
Corresponding frequency of
high-speed friction torque
1.00 Hz–400.00 Hz
50.00 Hz
7.4 SVPWM control
Goodrive35 series VFDs provide internal SVPWM control which can be used in the cases where it
does not need high control accuracy. It is also recommended to use SVPWM control when one VFD
drives multiple motors.
Goodrive35 series VFDs provide multiple V/F curve modes. The user can select the corresponding
V/F curve to the site needs. Or they can set the corresponding V/F curve to their own needs.
