Goodrive35 Series Closed-loop Vector Control VFD Optional peripheral accessories
281
reactor is configured.
3. The rated output voltage drop of output reactors is 1%±15%.
4. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
D.6.2 Reactors for AC 3PH 520 V (-15%)–690 V (+10%)
Note:
1. The rated input voltage drop of input reactors is 2%±15%.
2. The current adjustment coefficient on the input side of the VFD is higher than 90% after a DC
reactor is configured.
3. The rated output voltage drop of output reactors is 1%±15%.
4. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
D.7 Filter
J10 is not connected in factory for VFDs of 380V (≤110kW). Connect the J10 packaged with the
manual if the requirements of level C3 need to be met.
