INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
177
Function
code
Name
Detailed instruction of parameters
Default
value
through communication, and the
communication address is 0x200A.
P05.13
Terminals control running
mode
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0
P05.14
Switch-on delay of S1
0.000–50.000 s
0.000 s
P05.15
Switch-off delay of S1
0.000–50.000 s
0.000 s
P05.16
Switch-on delay of S2
0.000–50.000 s
0.000 s
P05.17
Switch-off delay of S2
0.000–50.000 s
0.000 s
P05.18
Switch-on delay of S3
0.000–50.000 s
0.000 s
P05.19
Switch-off delay of S3
0.000–50.000 s
0.000 s
P05.20
Switch-on delay of S4
0.000–50.000 s
0.000 s
P05.21
Switch-off delay of S4
0.000–50.000 s
0.000 s
P05.22
Switch-on delay of S5
0.000–50.000 s
0.000 s
P05.23
Switch-off delay of S5
0.000–50.000 s
0.000 s
P05.24
Switch-on delay of S6
0.000–50.000 s
0.000 s
P05.25
Switch-off delay of S6
0.000–50.000 s
0.000 s
P05.26
Switch-on delay of S7
0.000–50.000 s
0.000 s
P05.27
Switch-off delay of S7
0.000–50.000 s
0.000 s
P05.28
Switch-on delay of S8
0.000–50.000 s
0.000 s
P05.29
Switch-off delay of S8
0.000–50.000 s
0.000 s
P05.30
Switch-on delay of HDI
0.000–50.000 s
0.000 s
P05.31
Switch-off delay of HDI
0.000–50.000 s
0.000 s
P07.39
Present fault input
terminal state
0
P17.12
ON/OFF input terminals
state
0000–01FF
0
7.12 Digital input
Goodrive35 series VFDs have 2 relay output terminals and 1 Y output terminal and 1 high speed
pulse output terminal in the standard configuration. All functions of the digital input terminals are
programmable by the function codes. Open collector pole input can be selected into high speed pulse
input terminal or common switch input terminal by function code.
