INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
183
Function
code
Name
Detailed instruction of parameters
Default
value
P10.34
Simple PLC 0–7 step
ACC/DEC time
0x0000–0XFFFF
0000
P10.35
Simple PLC 8–15 step
ACC/DEC time
0x0000–0XFFFF
0000
P10.36
PLC restart
0: Restart from the first stage
1: Continue to run from the stop frequency
0
P05.01–P
05.09
Digital input function selection
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
P06.01–P
06.04
Digital output function
15: Underload pre-alarm
16: Completion of simple PLC stage
P17.00
Set frequency
0.00 Hz–P00.03 (max. output frequency)
0.00 Hz
P17.27
Simple PLC and present
stage of the multi-step speed
0–15
0
7.14 Multi-step speed running
Set the parameters when the VFD carries out multi-step speed running. Goodrive35 series VFDs can
set 16-stage speed which can be selected by the combination code of multi-step speed terminals 1–4.
They correspond to multi-step speed 0 to 15.
