INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Dimension drawings
267
Model
W1
W2
H1
H2
D1
Installation hole
Weight (kg)
160 kW–220 kW
500
180
870
850
360
11
85
Figure C-13 Wall installation of 660 V 250-350 kW VFDs
Model
W1
W2 H1 H2
D1
Installation hole
Weight (kg)
250 kW–350 kW
680
230 960 926
380
13
135
C.5.2 Flange installation (unit: mm)
Figure C-14 Flange installation of 660 V 22-132 kW VFDs
Model
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Installation
hole
Weight
(kg)
22 kW–45 kW
270
130
261
65.5
555
540
516
17
325
167
7
30
55 kW–110 kW
325
200
317
58.5
680
661
626
23
363
182
9.5
47
132 kW
325
200
317
58.5
680
661
626
23
363
182
9.5
85
