INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Optional peripheral accessories
270
Appendix D Optional peripheral accessories
D.1 What this chapter contains
This chapter describes how to select the options and parts of Goodrive35 series.
D.2 Peripheral wiring
Below is the peripheral wiring of Goodrive35 series VFDs.
Power
supply
Breaker
Input filter
Input reactor
Grounding
DC reactor
LED keypad LCD keypad
Standard
Optional
P1
+
+
-
PB
Brake
resistor
Brake unit
PC
RS485 to
RS232
converter
Output filter
Output reactor
Motor
Grounding
+
Upper PC
software
485
+
485
-
Note:
1. Built-in brake unit is included for 380 V 30 kW and below models;
2. P1 terminal is included for 380 V 37 kW and above models, which can be connected to external DC
reactor directly;
