Goodrive35 Series Closed-loop Vector Control VFD Product overview
13
Model
Output
power (kW)
Input current
(A)
Output current
(A)
Carrier frequency
( kHz)
GD35-220G-6-C1/D1/H1
220
230
240
115 (2)
GD35-250G-6-C1/D1/H1
250
255
274
115 (2)
GD35-280G-6-C1/D1/H1
280
286
300
115 (2)
GD35-315G-6-C1/D1/H1
315
334
328
115 (2)
GD35-350G-6-C1/D1/H1
350
360
380
115 (2)
GD35-400G-6-C1/D1/H1
400
411
426
115 (2)
GD35-500G-6-C1/D1/H1
500
518
540
115 (2)
GD35-560G-6-C1/D1/H1
560
578
600
115 (2)
GD35-630G-6-C1/D1/H1
630
655
680
115 (2)
Note:
1. The input current of VFDs 22350 kW is detected when the input voltage is 660 V and there is no
DC reactors and input/output reactors.
2. The input current of VFDs 400630 kW is detected when the input voltage is 660 V and there are
input reactors.
3. The rated output current is defined when the output voltage is 660 V.
4. The output current cannot exceed the rated output current and the output power cannot exceed the
rated output power in the voltage range.
3.7 Structure diagram
The VFD layout is shown below (take 380 V 30 kW as an example).
