Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
148
Function
code
Name
Detailed instruction of parameters
Default
value
P04.16
V/F frequency 1 of motor 2
0.00 Hz–P04.18
0.00 Hz
P04.17
V/F voltage 1 of motor 2
0.0%–110.0%
00.0%
P04.18
V/F frequency 2 of motor 2
P04.16–P04.20
00.00 Hz
P04.19
V/F voltage 2 of motor 2
0.0%–110.0%
00.0%
P04.20
V/F frequency 3 of motor 2
P04.18–P12.02 (rated frequency of AM 2) or
P04.18–P12.16 (rated frequency of SM 2)
00.00 Hz
P04.21
V/F voltage 3 of motor 2
0.0%–110.0%
00.0%
P04.22
V/F slip compensation
gain of motor 2
0.0–200.0%
100.0%
P04.23
Vibration control factor at
low frequency of motor 2
0–100
10
P04.24
Vibration control factor at
high frequency of motor 2
0–100
10
P04.25
Vibration control threshold
of motor 2
0.00 Hz–P00.03 (max. output frequency)
30.00 Hz
P04.26
Energy-saving operation
0: No action
1: Automatic energy-saving running
0
P04.27
Voltage setting
0: Keypad: the output voltage is determined
by P04.28.
1: AI1;
2: AI2;
3: AI3;
4: HDI1;
5: Multi-step speed;
6: PID;
7: Modbus communication;
8: PROFIBUS/CANopen communication;
9: Ethernet communication (reserved)
10: Reserved
0
P04.28
Keypad setting voltage
0.0%–100.0% (rated voltage of motor)
100.0%
P04.29
Voltage increasing time
0.0–3600.0s
5.0 s
P04.30
Voltage decreasing time
0.0–3600.0s
5.0 s
P04.31
Maximum output voltage
P04.32–100.0% (rated voltage of motor)
100.0%
P04.32
Minimum output voltage
0.0%–P04.31 (rated voltage of motor)
0.0%
7.5 Torque control
Goodrive35 series VFDs support two kinds of control mode: torque control and rotation speed control.
The core of rotation speed is that the whole control focuses on the stable speed and ensures the
