INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Optional peripheral accessories
278
Model
Breaker (A)
Fuse (A)
The rated working current
of the contactor (A)
GD35-5R5G-4-C1/D1/H1/H2
45
25
16
GD35-7R5G-4- C1/D1/H1/H2
60
40
25
GD35-011G-4- C1/D1/H1/H2
78
63
32
GD35-015G-4-C1/D1/H1/H2
105
63
50
GD35-018G-4-C1/D1/H1/H2
114
100
63
GD35-022G-4-C1/D1/H1/H2
138
100
80
GD35-030G-4-C1/D1/H1/H2
186
125
95
GD35-037G-4-C1/D1/H1
228
160
120
GD35-045G-4-C1/D1/H1
270
200
135
GD35-055G-4-C1/D1/H1
315
200
170
GD35-075G-4-C1/D1/H1
420
250
230
GD35-090G-4-C1/D1/H1
480
315
280
GD35-110G-4-C1/D1/H1
630
400
315
GD35-132G-4-C1/D1/H1
720
400
380
GD35-160G-4-C1/D1/H1
870
630
450
GD35-185G-4-C1/D1/H1
630
1110
580
GD35-200G-4-C1/D1/H1
1110
630
580
GD35-220G-4-C1/D1/H1
1230
800
630
GD35-250G-4-C1/D1/H1
1380
800
700
GD35-280G-4-C1/D1/H1
1500
1000
780
GD35-315G-4-C1/D1/H1
1740
1200
900
Note: The accessory specifications described in the preceding table are ideal values. You can select
accessories based on the actual market conditions, but try not to use those with lower values.
D.5.2 AC 3PH 520 V (-15%)–690 V (+10%)
Model
Breaker (A)
Fuse (A)
The rated working current
of the contactor (A)
GD35-022G-6-C1/D1/H1
105
63
50
GD35-030G-6-C1/D1/H1
105
63
50
GD35-037G-6-C1/D1/H1
114
100
63
GD35-045G-6-C1/D1/H1
138
100
80
GD35-055G-6-C1/D1/H1
186
125
95
GD35-075G-6-C1/D1/H1
270
200
135
GD35-090G-6-C1/D1/H1
270
200
135
GD35-110G-6-C1/D1/H1
315
200
170
GD35-132G-6-C1/D1/H1
420
250
230
GD35-160G-6-C1/D1/H1
480
315
280
