INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
160
Function
code
Name
Detailed instruction of parameters
Default
value
P08.06
Jogging frequency
0.00–P00.03 (max. output frequency)
5.00 Hz
P08.07
Jogging ACC time
0.0–3600.0 s
Depend on
model
P08.08
Jogging DEC time
0.0–3600.0 s
Depend on
model
P08.28
Fault reset times
0–10
0
P08.29
Interval time of automatic fault
reset
0.1–3200.0 s
1.0 s
7.8 Frequency setting
Goodrive35 series VFDs can set the frequency by various means. The given channel can be divided
into main given channel and assistant given channel.
There are two main given channels: A frequency given channel and B frequency given channel.
These two given channels can carry out mutual simple math calculation between each other. And the
given channels can be shifted dynamically through set multi-function terminals.
There are three assistant given channels: keypad UP/DOWN input, terminals UP/DOWN switch input
and digital potentiometer input. The three ways equal to the effect of input UP/DOWN given in
internal assistant given of the VFD. The user can enable the given method and the effect of the
method to the frequency given by setting function codes.
The actual given of the VFD is consisted of main given channel and assistant given channel.
