Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
151
Function
code
Name
Detailed instruction of parameters
Default
value
upper frequency of
reverse rotation
P03.18
Upper electromotion
torque source
0: Keypad setting upper-limit frequency
(P03.20)
1: AI1 (100% corresponds to three times of the
rated current of the motor)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: HDI (the same as above)
5: Modbus communication (the same as
above)
6: PROFIBUS/CANopen communication (the
same as above)
7: Ethernet communication (the same as
above)
0
P03.19
Upper brake torque
source
0: Keypad setting upper-limit frequency
(P03.21)
1: AI1 (100% corresponds to three times of the
rated current of the motor)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: HDI (the same as above)
5: Modbus communication (the same as
above)
6: PROFIBUS/CANopen communication (the
same as above)
7: Ethernet communication (the same as
above)
0
P03.20
Keypad setting of
electromotion torque
0.0–300.0% (rated current of the motor)
180.0%
P03.21
Keypad setting of brake
torque
0.0–300.0% (rated current of the motor)
180.0%
P17.09
Output torque
-250.0–250.0%
0.0%
P17.15
Torque reference
-300.0–300.0% (rated current of the motor)
0.0%
7.6 Parameters of the motor
 Physical accident may occur if the motor starts up suddenly during autotune.
Please check the safety of surrounding environment of the motor and the load
