INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Dimension drawings
265
Model
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Installation
hole
Weight
(kg)
37 kW–55 kW
270
130
261
65.5
555
540
516
17
325
167
7
30
75 kW–110 kW
325
200
317
58.5
680
661
626
23
363
182
9.5
47
Figure C-9 Flange installation of 380 V 132-200 kW VFDs
Model
W1
W2
W3 W4 H1 H2
H3
H4
D1
D2
Installation
hole
Weight
(kg)
132 kW–200 kW
500
180
480
60
870
850
796
37
358
178.5
11
85
C.4.3 Floor installation (unit: mm)
Figure C-10 Floor installation of 380 V 220-315 kW VFDs
