INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Optional peripheral accessories
283
Field identifier
Detailed instruction
L: General
H: High-performance
F
Filter application environment
A: Environment Category I, C1 (EN 61800-3:2004)
B: Environment Category I, C2 (EN 61800-3:2004)
C: Environment Category II, C3 (EN 61800-3:2004)
D.7.2 Filters for AC 3PH 380 V (-15%)–440 V (+10%)
Model
Input filter
Output filter
GD35-1R5G-4-C1/D1/H1
FLT-P04006L-B
FLT-L04006L-B
GD35-2R2G-4-C1/D1/H1
GD35-004G-4-C1/D1/H1/H2
FLT-P04016L-B
FLT-L04016L-B
GD35-5R5G-4-C1/D1/H1/H2
GD35-7R5G-4- C1/D1/H1/H2
FLT-P04032L-B
FLT-L04032L-B
GD35-011G-4- C1/D1/H1/H2
GD35-015G-4-C1/D1/H1/H2
FLT-P04045L-B
FLT-L04045L-B
GD35-018G-4-C1/D1/H1/H2
GD35-022G-4-C1/D1/H1/H2
FLT-P04065L-B
FLT-L04065L-B
GD35-030G-4-C1/D1/H1/H2
GD35-037G-4-C1/D1/H1
FLT-P04100L-B
FLT-L04100L-B
GD35-045G-4-C1/D1/H1
GD35-055G-4-C1/D1/H1
FLT-P04150L-B
FLT-L04150L-B
GD35-075G-4-C1/D1/H1
GD35-090G-4-C1/D1/H1
FLT-P04240L-B
FLT-L04240L-B
GD35-110G-4-C1/D1/H1
GD35-132G-4-C1/D1/H1
GD35-160G-4-C1/D1/H1
FLT-P04400L-B
FLT-L04400L-B
GD35-185G-4-C1/D1/H1
GD35-200G-4-C1/D1/H1
GD35-220G-4-C1/D1/H1
FLT-P04600L-B
FLT-L04600L-B
GD35-250G-4-C1/D1/H1
GD35-280G-4-C1/D1/H1
GD35-315G-4-C1/D1/H1
FLT-P04800L-B
FLT-L04800L-B
Note:
1. The input EMI meets the C2 requirements after an input filter is configured.
2. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
