Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
164
Function
code
Name
Detailed instruction of parameters
Default
value
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting valid
LED tens: Frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: Invalid for multi-step speed when multi-step
speed takes priority
LED hundreds: Action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving
the stop commands
P08.45
UP terminals frequency
changing ratio
0.01–50.00 Hz/s
0.50 Hz/s
P08.46
DOWN terminals
frequency changing ratio
0.01–50.00 Hz/s
0.50 Hz/s
P17.00
Setting frequency
Range: 0.00 Hz–P00.03 (max. output
frequency)
0.00 Hz
P17.02
Ramp reference frequency
Range: 0.00 Hz–P00.03 (max. output
frequency)
0.00 Hz
P17.14
Digital adjustment
0.00 Hz–P00.03
0.00 Hz
7.9 Analog input
Goodrive35 series VFDs have three analog input terminals and 1 high-speed pulse input terminals (of
which, AI1 and AI2 are 0–10 V/0–20mA and Al can select voltage input or current input by J3, AI2 can
select voltage input or current input by J4 and AI3 is for -10–10 V) as the standard configuration. The
inputs can be filtered and the maximum and minimum values can be adjusted.
