INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-99-
Function
code
Name
Description
Default
P05.00
HDI input type
0x00–0x11
Ones place: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens place: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P05.38
HDIA high-speed pulse input
function selection
0: Input set through frequency
1: Reserved
2: Input set through encoder, used together
with HDIB
0
P05.44
HDIB high-speed pulse input
function selection
0: Input set through frequency
1: Reserved
2: Input set through encoder, used together
with HDIA
0
P18.00
Actual frequency of encoder
-999.9–3276.7Hz
0.0Hz
P20.15
Speed measurement mode
0: PG card
1: Locally measured through HDIA and
HDIB. Only the 24V incremental encoders
are supported.
0
5.5.16 Fault handling
The following provides fault handling information.
In running
Fault occurred, and the
keypad displayed fault
code
Figure out the fault
cause based on the
fault code
Figure out the most possible
cause according to P07.33–
P07.40
Run again
Proper running
Rule out
fault based on
corresponding
solutions
Consult with INVT
Y
N
N
Y
